MB A3
Circular RFID antenna
This antenna goes a step further than the MB A2 antenna in terms of directivity and range. These qualities make the antenna perfect for applications requiring very focused coverage in terms of distance and accuracy.
Verticals
- Retail: Fashion store
- Retail: Logistics
- Industry: Logistics
Applications
- Asset traceability systems
- Kiosks / Self-service totems
and self-service totems and self-payment
Parameters
| Polarization | Circular (RHCP) |
| Frequency | 865-868 MHz |
| Gain | 9 dBi |
| Impedance | 50 Ω |
| Ratio front to rear |
17 dB |
| SWR (VSWR) | < 1.2:1 |
| Axial ratio | < 1 dB |
| Beamwidth at half power | 45°/ 73° |
Mechanics
| Connector | SMA female |
| Dimensions | 370 x 195 x 17 mm |
| Weight |
0.51 kg |
Optimum temperatures
| Operation | -20 to 70 ºC |
| Storage | < 23 ºC temperature < 50 % RH humidity |
